From classification, structure to characteristics, the three basic knowledge of drag chain are explained in detail Turkey Excavator sprocket
Engineering plastic towline is suitable for CNC machine tools, machining centers, automated machinery and production lines and other types of machine tools, robots, transportation machinery, measuring instruments, handling devices and other drive controls. The moving parts of the bed and mechanical equipment operate in a coordinated manner, and play the ability of safety protection and guidance, which can prolong the service life of the protected wires, cables, liquid and gas hoses and reduce consumption. The disorderly distribution of the liquid and gas hoses has a good improvement effect, which can make them neatly and orderly arranged and distributed regularly, and greatly enhance the overall artistic modeling effect of machine tools and mechanical equipment.Turkey Excavator sprocket
Classification of e-chains Turkey Excavator sprocket
According to the material classificaTurkey Excavator sprockettion, engineering drag chains can be divided into plastic engineering drag chains and steel engineering drag chains. According to the structure classification, it can be divided into bridge engineering drag chain and fully enclosed engineering drag chain. The internal height of the engineering plastic drag chain varies from 10-80 (mm), and the width varies from 10-350 (mm), which is generally determined according to the size and quantity of the cables that the user wants to protect.Turkey Excavator sprocket
The strength of the drag chain mainly depends on the nylon content contained in the raw material. According to the strength of use, engineering plastic towline is divided into ordinary engineering plastics towline and reinforced engineering plastics towline. In a relatively harsh environment, a fully enclosed engineering towline is generally used.Turkey Excavator sprocket
Features of e-chains
1. The appearance is beautiful and simple, the weight is light, and the length can be adjusted arbitrarily according to the requirements of use;
2. It is suitable for the occasion of reciprocating motion, and can pull and protect the built-in cables, oil pipes, air pipes, water pipes, etc.;
4. Each section of the towline can be opened for easy installation and maintenance;
5. When the towline is in motion, the noise generated is low, and the wear resistance is good, and it can also be used for high-speed motion.
The structure of the energy chain
We can clearly see that the shape of the drag chain is very similar to that of the tank. It is composed of many unit chain links, and the chain links can rotate freely. The drag chains of the same series have the same inner height, outer height and pitch, and the inner height and bending radius r of the drag chains can be selected differently. The unit chain link is composed of left and right chain plates and an upper cover plate. Each link can be opened, which is convenient for loading and unloading. There is no need to thread.Turkey Excavator sprocket
